Connecting CPA to Macintosh
KX-RC22 is an interface adaptor for data transfer with Macintosh.
A Macintosh to Modem cable (serial cable) must be purchased before
connecting. The following cable is needed:
Macintosh C7=r
8P Mini Din
fi
(male)
Interface adaptor
25P DB-25
(male)
¡Note:
For pin configuration, refer to Modem or Printer port’s specifi-
cation of the Macintosh.
?
3
3
rt>
0
(Q
r>
2
1
o
3
(n
3-
3^' i, Turn off the Macintosh, the interface adaptor, and then the CPA.
Note:
When the CPA is connected to the Macintosh, turn off al! the
power switches otherwise the electronic circuit may become dam
aged, and the data or the contents of the memory may change.
Note:
When an interface cable is not plugged into the jack, insert the
jack cover. Dust or dirt particles may get into it or static electricity
may occur around it.
