Specifications
GENERAL
Power Supply
Maximum Power Output
Power Output
Tone Action
Current Consumption
Pre-Amp Output Voltage
Speaker Impedance
Dimensions (W x H x D)
Weight
12 V DC (11 V -16 V) Test Voltage 14.4 V, Negative ground
30 W X 4 channels at 400 Hz, Volume Control maximum
15 W per channel into 4 ii, 40 to 30,000 Hz at 3
%
THD.
Bass ; ± 12 dB at 100 Hz
Treble; ± 12 dB at 10 kHz
Less than 2.5 A (tape mode, 0.5 W 4-speaker)
2.0V (CD Play mode: 1kHz 0 dB)
4 Q (4 - 8 Q acceptable)
?■ X 1-15/16" X 5-7/8" (178 x 50 x 150 mm) .
3 lbs. 8 oz. (1.6 kg)
AM RADIO
Frequency Range
Useable Sensitivity 530- 1,710 kHz
28 dB/pV (25 pV/ S/N 20 dB)
FM STEREO RADIO
Frequency Range
Useable Sensitivity
50 dB Quieting Sensitivity
Frequency Response
Alternate Channel Selectivity
Stereo Separation
Signal/Noise Ratio
87.9- 107.9 MHz
12dBf. (1.1 pV/75ii, S/N 30 dB)
17dBf. (1.8 pV/75 H)
30- 15,000 Hz ±3dB
75 dB
35 dB at 1,000 Hz
70 dB (Mono)
TAPE PLAYER
Reproduction System
Tape Speed
FF/REW Time
Frequency Response
Wow and Flutter
Signal/Noise Ratio
4-track, 2-program stereo
1-7/8"/sec (4.76 cm/sec)
Less than 200 sec (C-60)
35- 14,000 Hz ±3dB
0.12%(WRMS)
52 dB
’Above specifications comply with EIA standards.
Note:
Specifications and design are subject to modification without notice due to improvements in technology.
Part 15 of the FCC Ruies
(This standard is for U.S.A Only)
This unit has been manufactured under the part 15 of the FCC Rules.
Do not attempt to make any changes or modifications to this unit.
CO-R145U
25
