CONNECTIONS

Caution:

Keep the POWER switch of the specified monitor, Camera Extension Unit and

Camera Drive Unit in OFF position while making connections. If the power of these units
is ON during connections, the camera does not function due to the built-in protection

circuit which protects it against wrong connections.

Basic System

Connect the coaxial cables between the camera and CAMERA IN connector of the
specified monitor or Camera Drive Unit. The approximate maximum cable length is as

follows:

Coaxial
Cable Type

Maximum
Cable Length

DC R/1000 ft. of
Inner Conductor

RG-59/U

RG-6/U

200 m (660 ft)
500 m (1 650 ft)

Less than 30 n
Less than 12 ii

The maximum DC resistance between the camera and these unit is 20 fl.

Cameras
