Between Antenna and VCR

Between VCR and TV

Case 1; Twin Lead Cable Only

To VCR Terminal

(Flat) Twin Lead

300 Ohm Cable

n®

300-75 ohm Transformer
(not supplied)

Case 1: Screw & Plug Type Terminal

UHFA/HF Band
Separator
(not supplied)

RF Coaxial Cable

VHF

UHF

Case 2: Twin Lead & Coaxial Cables

(Round) 75 Ohm

coaxial Cable

UHFA/HF
Band Mixer

(not supplied)

To VCR Terminal

Case 3: Two Twin Lead Cables

(not supplied)

To VCR Terminal

If your TV has both post and plug-type VHF

terminals, the post connection is recommended to

minimize signal loss.

Case 2: Screw Type Terminal

VHF

UHF

Case 3: Double Screw Type Terminal

UHFA/HF Band

Separator

(not supplied)

VHF

UHF

Case 4: Complex TV Terminal

TERMINALS ON BACK OF TV SET

• Connect to one of the ANT terminals and select the

same antenna number on the TV.
