Basic Connection
or
V
1
Disconnect the antenna or
cable from your TV and connect
it to the VCR (IN FROM ANT.)
(
VCR)
3
Set the Output Channel of your VCR
to Channel 3 or 4 (whichever is not being
transmitted on by a Local TV broadcast).
Cable TV
or
RF Coaxial Cable
(VCR-TV Connection Cable) (supplied)
2
Connect the VCR to your TV with
the RF Coaxial Cable (OUT TO TV).
r WARNING-----------------------------------------------------------------------------------------------------------------------------
When using “Nut type" RF coaxial cables, tighten with fingers only. Overtightening may damage terminals.
