Panasonic AJ-D255MC - Manual (Page 9)

CASSETTE COMPARTMENT ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
102 VMX0967 CUT WASHER 14
1 VXA7347 FRONT LOADING ASS’Y 1 (M) 103 VMX1061 WASHER 4
2 VMS5865 MAIN SHAFT 1 104 XQN16+A2FJ SCREW 7
3 VMA0T36 TOP PLATE 1 105 XYN2+C4FJ SCREW 4
4 VMA0M72 FRONT GUIDE 1 ASS’Y 1 108 XQN2+A3FJ SCREW 5
5 VMB3075 M GUIDE SPRING 2 109 LMHD16064 SCREW 11
6 VML3191 M GUIDE RIGHT LEVER 1 110 XUC25FP E-RING 1
7 VML3192 M FRONT GUIDE 2 111 XWGV2Z5G WASHER 2
8 VML3190 M GUIDE LEFT LEVER 1 113 VHD1323 SCREW 9
9 VML3397 CASSETTE PROTECT PLATE 1 114 XYN2+J4FJ SCREW 2
11 VMZ3233 FPC PROTECTOR 1
12 VMB2926 SPRING 1
13 VML2A50 BLINDER PANEL OPENER 1
14 VXA7355 SIDE PLATE R 1 ASS’ Y 1 E18 VEP80856A CARRIGE P.C.BOARD 1
15 VML3282 SUB RAIL (R) 1
16 VEK7695 SIDE FLEXIBLE 1
17 VXA5766 MAIN RACK R ASS’Y 1
18 VDG1156 WIPER RACK 2
19 VMZ3259 FPC COVER 1
20 VDB1395 MAIN SHAFT ANGLE 2
21 VDG1412 INTERLOCK GEAR 2
22 VML3193 OPENER DRIVE ARM 1
23 VXL2692 OPENER ANGLE ASS’ Y 1
24 VMB2979 SPRING 1
25 VXA7353 SIDE PLATE L 1 ASS’ Y 1
26 VML3281 SUB RAIL (L) 1
27 VDG1413 INTERAMEDIATE GEAR 1
28 VDP1643 WIPER ROLLER 2
29 VDG1414 CLUTCH GEAR 1
30 VMB2980 CLUTCH SPRING 1
31 VDG1236 WORM WHEEL 1
32 VXA5848 MOTOR ANGLE (A) ASS’Y 1
33 VXP1797 E. E SLOT IN WORM ASS’ Y 1
34 VXA5597 MOTOR ASS’Y 1 (M)
35 VMA9673 EMERGENCY ANGLE 1
36 VEK7793 MOTOR P. C. BOARD 1
37 VMA9668 HOLDER PLATE 1
38 VEK7715 HOLDER FLEXIBLE ASS’Y 1
39 VXA6075 MAIN RACK (L) ASS’Y 1
40 VML3485 WIPER ARM (R) 1
41 VMB3390 WIPER SPRING (L) 1
42 VDG1163 WIPER GEAR 2
43 VMB3391 WIPER ARM (L) 1
44 VML3484 WIPER SPRING (R) 1
45 VDP1642 CASSETTE GUIDE ROLLER (2) 2
46 VDP1641 CASSETTE GUIDE ROLLER (1) 2
47 VXA5757 CASSETTE HOLDER 1 ASS’ Y 1
48 VXA5758 ROD L 1
49 VXA5759 ROD R 1
50 VMB3064 SLIDE SPRING 2
51 VML3249 SIDE GUIDE L 1
52 VML3250 SIDE GUIDE R 1
53 VMB3061 SLIDE GUIDE SPRING L 1
54 VMB3062 SLIDE GUIDE SPRING R 1
55 VMS6108 KICK OFF ROD SHAFT 2
56 VML2A54 KICK OFF ARM L 1
57 VML2A55 KICK OFF ARM R 1
58 VMB2928 KICK OFF SPRING 2
59 VML2A53 CASSETTE HOLDER ARM 2
60 VMB2927 CASSETTE HOLDER SPRING 2
61 VMX2833 M-L DETECT ROLLER 2
62 VMS5882 CASSETTE HOLDER SHAFT 1
63 VMB3253 M-L DETECT SPRING 2
64 VMX2559 CASSETTE PRESSURE ROLLER(2) 3
65 VMX2524 CASSETTE PRESSURE ROLLER(1) 2
66 VDG1246 EMERGENCY GEAR 1
67 VMB3109 EMERGENCY SPRING 1
69 VEE9577 CABLE 1
70 VMZ3040 SHIELD PLATE 1
71 VMS7087 GUIDE LEVER PIN 1
72 VEE9632 MOTOR CABLE 1
101 VMX0653 CUT WASHER 4
MPL-9
