FRONT JACK ASSEMBLY
Ref. No. Part No. Part Name & Description Pc; Remarks Ref. No. Part No. Part Name & Description Pc; Remarks
1 VGU5582 SWITCH KNOB 5
2 VGU5605 KNOB 1
3 VMB2923 BLINDER SPRING 1
4 VMP8227 TOP PLATE SUPPORT ANGLE 1
5 VGF0836 PANEL SHEET 1
6 VYP9058 FRONT PANEL (1) ASS’Y 1
6-1 VGU9679 KNOB HOLDER 1
6-2 VGU9680 KNOB HOLDER B 1
6-3 VGU9682 OPERATION BUTTON A 1
6-4 VGU9683 OPERATION BUTTON B 4
6-5 RGB0116-S PANASONIC BADGE 1
6-6 VGB0637 DVC BADGE 1
6-7 VGU8377 EJECT KNOB 1
6-8 VYQ2807 CASSETTE GUIDE ASS’ Y 1
6-9 VMB3564 CASSETTE GUIDE SPRING 2
6-10 VMB3565 CAM SPRING 2
6-11 VMX2562 WASHER 8
7 VGF1008 SLIDE SW SHEET 5
8 VGF1017 JOG KNOB SHEET 1
9 VGU9681 JOG KNOB 1
10 VKF2785 BLINDER PANEL 1
11 L6FAHBBD0002 FAN MOTOR 1
12 VJF0300 A/C HEAD BINDER 1
13 K1YE50000008 FIX SCREW 2
14 VJH1246 JACK PANEL 1
15 VMP8138 AV JACK BLANK PANEL 1
16 VMP8141 CONNECTOR SUPPORT ANGLE A 1
17 VGF1022 FAN BARRIER 1
19 VMT1646 GASKET 3
20 VMP8148 AV JACK PANEL 1
21 VMP8142 CONNECTOR SUPPORT ANGLE 1
22 VGH4792 AV JACK SHEET 1
23 VGF1029 XLR BLIND SHEET 1
101 XTV3+6GFJ SCREW 7
102 XUC2FP E-RING 2
103 XUC25FP E-RING 2
104 XYN3+J6FJ SCREW 5
105 XTV3+6FFJK SCREW 8
106 XTN3+10JFJK SCREW 7
107 XYN3+J20FJK SCREW 2
109 XYN4+E6VW SCREW 1
110 XSN26+6FJK SCREW 4
E12 VEP80D21C OPT JACK P. C. BOARD 1
E13 VEP80D20A STD JACK P. C. BOARD 1
E14 VEP86342B FRONT P. C. BOARD 1
E15 VEP80D16A FRONT SUB P. C. BOARD 1
E16 VEP80D17A EJECT P. C. BOARD 1
E17 VEP80D22A UPPER SW P. C. BOARD 1
MPL-13
