SHASSIS & FRAME ASSEMBLY Components identified with the mark ^ have the speciai characterisitics for safety.
When repiacing any of these components, use oniiy the same type.
Ref. No. Part No. Part Name & Description Pcs Remarks Ref. No. Part No. Part Name & Description Pcs Remarks
1 VGF0762 DUST PROOF SHEET (B) 1
2 VGU8051 POWER BUTTON 1
3 VJF0004 WIRE SADDLE 2
4 VJF0456 BINDER 1
5 VJF0861 BUSH 1
6 VJF1158 CLAMPER 1
7 VMP8126 SIDE FRAME R 1
8 VMP8128 BACK FRAME 1
9 VMP8129 FRONT FRAME 1
10 VMP8132 MECHA EXT FIX ANGLE 1
11 VMP8133 PCB FIX ANGLE 1
12 VSC5658 MECHA GND ANGLE 1
13 VXA7990 MECHA FRAME ASS’Y 1
14 VXA7900 P. C. B. PLATE ASS’ Y 1
14-1 VMX3433 PCB RUBBER CUSHION A 1
14-2 VMX3434 PCB RUBBER CUSHION B 1
15 VXA7901 CENTER FRAME ASS’ Y 1
15-1 VGF1016 DUSTPROOF SHEET D 1
15-2 VMT0976 DUST PROOF CUSHION (F) 1
15-3 VMT1002 DUST PROOF CUSHION (O) 1
16 VGF1015 DUSTPROOF SHEET A 1
17 VGM1569 HANDLE COVER 1
18 VKH0388 HANDLE 1
19 VMP8414 HANDLE ANGLE 2
20 VMP8125 SIDE FRAME L 1
21 VMX2958 HANDLE SPACER 2
22 VEK0G89 POWER U 1
22-1 VSC5645 POWER CASE (LOWER) 1
22-2 VSC5646 POWER CASE (UPPER) 1
A 22-3 VMZ3482 POWER BARRIER A 1
A 22-4 VMZ3483 POWER BARRIER B 1
22-5 VMT1645 GASKET 1
A 22-6 VMZ3516 POWER DUCT SHEET 1
23 VES0945 POWER SW ASS’ Y 1
101 XSS4+14FJK SCREW 2
102 XTV3+6FFZ SCREW 2
103 XSB3+4FJ SCREW 2
104 XTV3+6FFJ SCREW 43
105 XYN26+J5FJ SCREW 3
106 XYN4+E6^ SCREW 1
107 XSN3+6FJK SCREW 2
108 XYN3+F8FJ SCREW 8
E1 VEP80D18B MOTHER P. C. BOARD 1
E2 VEP83647C F3 DPROC P. C. BOARD 1 FOR AJ-SD255P
E2 VEP83647D F3 DPROC P. C. BOARD 1 FOR AJ-SD255E/D255MC
E3 VEP83646A F2 AVMON P. C. BOARD 1
E4 VEP82253B F1 SERVO P. C. BOARD 1
E5 VEP85221A RF/CUE P. C. BOARD 1
E6 VEP83648B AVIO P. C. BOARD 1
E7 VEP81236A POWER 1 P. C. BOARD 1
E8 VEP81238A POWER 2 P. C. BOARD 1
E10 VEP82254A MECHA IF2 P.C.B.OARD 1
E11 VEP82255C MECHA IF3 P.C.BOARD 1
MPL-15
