Panasonic NE-1757 - Manual (Page 32)

Technical Specifications
NE-1257 NE-1757
Power Source 120 V, 60 Hz, single phase 208/230 V, 60 Hz, single phase
Required Power 177 A 14 3 A (208 V)
(Voltage) 13 3 A (230 V)
Receptical Required 20 AMPNEMA#5-20R 15AMPNEMA#6-15R
20 AMP NEMA # 6-20R
Output* HI 1200W HI1700W
MED 600 W MED 850 W
DEF 340 W DEF 340W
Frequency 2450 MHz
Outer Dimensions 16%" X 20" X133/16"
(WxDxH) (422 mm x 508 mm x 335 mm)
Cavity Dimensions 13" х 123/ з 2" х 6%"
(WxDxH) (330 mmx310 mmx175 mm)
Net Weight 26 3 kgs, 58 lbs 28 3 kgs, 62 lbs
Timer 30 min (digital)/10 touch pads
Maximum programable time for single stage heating
HI and MED power= 15 min
DEF power=30 min
Panasonic
MATSUSHITA HOME AND COMMERCIAL
PRODUCTS COMPANY, DIVISION OF
MATSUSHITA ELECTRIC CORPORATION
OF AMERICA
One Panasonic Way 4A-4
Secaucus, NJ 07094
Or Call (201)348-5377
B00033650AP
Specifications subject to change without notice Printed in U S A
