E. Memory Pad Heating for Both Single and 2 Stage Heating
[Make sure the unit is properiy programmed (see page 10.)]
1. Make sure the unit is plugged into a property grounded electrical outlet.
n
u
(1 stage) {2 stage)
PROG -/
rt n
R5 J U U
FRM I /*7 /-/
R3 J LI U
STAOE
(1 Stage) (1 stage)
2. Open the door. The cavity light will come on. The cooling fan will start
if the oven has been operating. “0" will appear in the display window.
3. Put the food into a suitable container and place it In the center of the oven.
Close the door.
4. Touchthe desired Memory Pad.
• 1 Stage Heating: “PROG”, Pad number, heating time, power level and “1” will
be displayed.
•2 Stage Heating: "PROG”, Pad number, total heating time for both stages, "1"
and “2” and power levels will be displayed.
[Example]: Memory Pad 5. (1 stage)
Memory Pad 3. (2 stage)
5. Touch Start pad.
• 1 Stage Heating: “1 ” and power level indicators blink while heating time counts
down.
•2 Stage Heating: First stage indicator “1" and the first stage power level blink
while heating time counts down.
At the end of the first stage heating time, one beep tone will
sound and the oven will shift to second stage heating. Count
down continues but now the “2” and second power level blink.
6. When all time expires, the end of the cycle Beep Tone will sound. All heating will
stop. The cavity light and the fan will go off. The time display will blink “0” until
the door is opened.
7. Open the door and remove the food. Close the door. One minute later the
display window will go blank and the fan will stop.
F. To read the Cycle Counter
1. Make sure the unit is plugged into a properly grounded electrical outlet.
3
/------------- I-T
/ /
/ /
c c c r
ULI UO
o n o n
9 -/_/ _/r/
2. Open the door and leave it open. The cavity light will come on. The cooling fan will start if
the oven has been operating. “0” will appear in the display.
3. While touching the STOP/RESET Pad press each Memory Pad. The display shows the
number of times each Memory Pad has been used. Within 3 seconds, touch the
Power Level Selector Pad to show the number of times the oven has been used in the
manual mode.
[Example]: 6666
4. Remove your finger from STOP/RESET Pad and quickly close door while the display is
still showing a Pad’s cycle count. The display will now show the total cumulative number
of times the oven has been used.
[Example]: 99999
One minute later, the display window will go blank and the fan will stop
automatically.
Note: Total cumulative number includes programmed memory heating andl
manual heating number of times oven has been used.
5. Individual pads will count cycles up to 9999, and then reset to zero. Total cycle count will
count cycles to 99,999, and then reset to zero. Cycle count cannot be reset to zero
manually.
-
