On Screen Displays (OSD)
Channel & Function Display
Whenever the channel is
changed, the Channel
number followed will appear
for a few seconds on-screen.
(Some station names may
also appear.)
When a function button is
pushed (PLAY, FF, etc.)
the VCR mode will be
displayed.
08
Menu Screen
Warning and Instruction Displays
These displays will alert you to a missed operation
provide further instructions.
or
WNET
If no active channels are
found for CHANNEL
MEMORY...
r
NO CH FOUND
PLEASE CHECK ANTENNA
CABLE CONNECTION THEN
PUSH VCR CH UP KEY AGAIN
k______________________________ <
If you attempt to set or
review a Timer Recording
and the Clock is not set...
PLEASE SET CLCKK
BEFORE PROGRAMMING
1
Push MENU to display
the menu.
2
Rotate and push the wheel
to make your selection
(see page 10).
....................... MENU ..........................
SET UP VCR
SET UP CHANNEL
ID ICHM/ LANGUE:ENOU SH
SELECT
SET
END
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
To get the most from each feature, it is
recommended that you read the Operation
Manual before attempting any operation.
If a Timer Program was not
completed before exiting
the Program mode...
PROGRAM IS INCOMPLETE
VCR Status & Clock Display
Push DISPLAY to display and remove the
overlay shown below.
Rec Time
Remaining
(OTR mode only
see page 18.)
Function Status
\
Time
REC
12:00AM WNET-
^0:25
0:00:00
1 SLP
'
___________ _______
Channel &
Call Letter
Tape Speed
Counter
Blank Tape and will be Blue Screen
If a blank section of tape is encountered in the Play
mode or the channel you select has no broadcast,
the TV screen will change to a solid blue field.
The screen will remain blue until a recorded signal
is again detected or an active channel is selected.
After a Timer Program
has been set...
TURN VCR OFF
FOR TIMER RECORDING
If you Push REC on the
remote control or REC
and PLAY on the VCR,
and a cassette is inserted
with no record tab...
If you Push PLAY, FF, REW,
or REC on the remote control
or if you push REC and
PLAY, PUY, FF, REW, or
REC on the VCR without a
cassette inserted...
If you Push POWER or
STOP during a Timer
Recording...
(visible in VCR mode only)
CHECK CASSETTE
RECORD TAB
r
NO CASSETTE
PLEASE INSERT A CASSETTE
TO CANCEL TIMER BEC
PUSH POWER THEN STOP KEY
13
