D e v i c e V i e w s

C h a s s i s D e v i c e V i e w

S p e c t r u m E n t e r p r i s e M a n a g e r

Page 28

S m a r t S w i t c h 6 0 0 0

you select Admin via the E1 Repeater label, the
Repeater Port labels associated with E1 (i.e., Ports
1 through 12) will display the administrative
status.

Repeater Port Labels

The 6E123-50 and 6E133-49 modules have 10
Mb repeater ports while the 6H123-50 and
6H133-37 modules have the capability of
switching ports between 10 Mb and 100 Mb
repeaters. For example, a 6H133_37 model would
have three 100 Mb repeater models, but
depending on the configuration, it might have six
repeater models, three at 10 Mb and three at 100
Mb. The CsRipEnetRptr application is used for all
these modules for either 10 Mb or 100 Mb
support.

The Chassis Module Icon provides Repeater Port
labels, which allow you to perform repeater port
management. The views accessible from the
Repeater Port label Icon Subviews menu are listed
in

Table 9

Table 9:

Repeater Port Label Icon Subviews

Repeater Port Number

Shows an index number identifying a particular
repeater port.

Repeater Port Status

Indicates the port activity status.

The Repeater Port Frame & Error Breakdown view
and Repeater Port Frame Size & Protocols view
provide pie charts and tables that are similar to
what is described for the

Repeater Frame & Error

Breakdown View (page 27)

and the

Repeater

Frame Size & Protocols View (page 27)

Menu

Selection

Description

Port Notes

Opens a note pad for your use.

Port Frame &
and Error
Breakdown

Opens the Repeater Port Frame &
Error Breakdown view.
