D e v i c e V i e w s

C h a s s i s D e v i c e V i e w

S p e c t r u m E n t e r p r i s e M a n a g e r

Page 26

S m a r t S w i t c h 6 0 0 0

Repeater Labels

The 6E123-50, 6E133-49, 6H123-50, and 6H133-
37 modules have repeater ports. The repeater
ports on the 6E123-50 and 6E133-49 have a fixed
port speed of 10Mb while those on the 6H123-50
and 6H133-37 can be switched between 10 Mb
and 100 Mb. The repeater application
(CsRipEnetRptr) is used for 10 Mb and 100 Mb
support on all of these modules, see the

CsRipEnetRpt Repeater Application (page 46)

The Chassis Module Icon provides repeater
management via the Repeater labels, which
display repeater status and provide access to
views that display performance, configuration,
and frame statistics information.

The Repeater labels also let you control what type
of status is displayed on the Repeater Port labels
(administrative, link, or speed status), see

Repeater Port Display Form (page 27)

. The

Repeater Port Labels (page 28)

let you set the

repeater port speed. The Repeater labels contain
the following labels.

Repeater Index

Identifies the repeater and provides double-click
access to the

Repeater Configuration View (page

56)

Repeater Status

Displays the repeater operational status and
provides double-click access to the Performance
View, which is described in SPECTRUM Views.
