Appendices
6‐10 DX15 User Guide
CHANGING THE FUSE IN THE VEHICLE POWER ADAPTER
The 100845‐000 Vehicle Power Adapter includes a fuse to protect against
excessive current draw. The fuse can be replaced with a fuse meeting the
following specifications:
 Glass tube / barrel type
 0.25 inches (6.3mm) x 1.25 inches (32mm)
 2A, 250V
 Fast‐acting
To reassemble the Vehicle Power Adapter, insert the four (4) pieces into
the cavity at the tip of the Adapter, in the following order:
 Spring.
 Fuse.
 Screw the knurled nut (with the tip inserted).
 Hand‐tighten the knurled nut until snug.
Appendix H: Connecting a Headset / Push‐to‐Talk Switch
Connection to a headset, microphone, and/or
Push‐to‐Talk switch requires the optional
100844‐000 Headset / Push‐to‐Talk Adapter
Cable. This cable and its connectors are
configured for headset connections common in
aviation.
Note: When the 100844 Headset Adapter Cable
is plugged in, your DX15's built‐in microphone
and speaker are disabled.
