EdgeAccess Universal Chassis System
L357 Gigabit Ethernet Service Unit 6-1
Chapter 6
Specifications
See also the specifications for the chassis or standalone enclosure.
6.1 L357 Specifications
Physical Specifications
Dimensions:
3.0"H x 1.0"W x 9.0"D (7.6 cm x 2.5 cm x 22.8 cm)
Weight: 0.3 lb. (0.136 Kg)
Operating Temperature: 0° to 50° C
Operating Humidity: Up to 90% (non-condensing)
Power Consumption: 5 VDC 800 mA, Maximum
Optical Connectors: SC
Regulatory Compliance
• ETL, ETLc (UL 60950/CSA C22.2 No. 60950)
• EN 60950
• EN 60825-1
• FCC Part 15B, Class A
• EN 55022
• EN 55024
• EN 61000-3-2
• EN 61000-3-3
• R&TTE Directive (EN 300-386)
• C-Tick (AS/NZS 3548)
• NEBS Level 3 Tested and Certified
• CE Mark
6.2 L357 Models
Model Fiber Optic Options, Extension Port
1000Base-T to 1000Base-X
User Port: 10/100/1000M UTP RJ45
L357-1110
1000BASE SX 850 nm MM 6 dB SC
L357-1113 1000BASE LX 1310 nm SM 7 dB SC
L357-1323 1000BASE LD 1310 nm SM 14 dB SC
L357-1333 1000BASE XD 1310 nm SM 21 dB SC
L357-1533 1000BASE ZX 1550 nm SM 21 dB SC
L357-1543 1000BASE EX 155 0 nm SM 23 dB SC
