CanogaView
®
Smart Element Manager
Enterprise Version
27
à 5U Chassis View
Graphical display for an individual 5U Chassis
à Alarm Monitor
Alarm filter for the selected Chassis and its
components
à Telnet
Telnet to the DMM managing the domain
à Reports
Chassis specific reports for this chassis and all of
its components
à Chassis Status
Chassis level status
à CIM View
Graphical display of CIM device
à Alarm Monitor
Alarm filter for this device only
à Telnet
Telnet to the DMM managing the domain
à Status
CIM module level status
à Configuration
Display and edit CIM level features
à DMM View
Graphical display of DMM device
à Alarm Monitor
Alarms filtered for this device only
à Telnet
Telnet to the DMM managing the domain
à Status
DMM module level status
à Configuration
Display and edit DMM level features
à Reset
Reset the selected DMM device
à Power Supply – AC View
Graphical display of 5U AC Power Supply
à Alarm Monitor
Alarms filtered for this device only
à Telnet
Telnet to the DMM managing the domain
à Power Supply – DC View
Graphical display of 5U DC Power Supply
à Alarm Monitor
Alarms filtered for this device only
à Telnet
Telnet to the DMM managing the domain
à LAN Extension Products View
Graphical display of 1230 device and installed 3xx
slot devices. This level will be bypassed if the
user selects one of the devices within a slot vs the
1230 device.
à Alarm Monitor
Alarms filtered for this 1230 device and installed
devices
à Telnet
Telnet to the DMM managing the domain
à Status
1230 module level status
à Configuration
Display and edit 1230 device level features
à Reset
Reset or Reset/Swap options for one or all
installed slot devices
à Device 3xx View
Graphical display of individual 3xx Lan device –
circuit view displayed if side band mgmt available
for the type of 3xx device installed
à Alarm Monitor
Alarm filter for the 3xx device selected
à Telnet
Telnet to the DMM managing the domain
à Status
3xx module level status
à Configuration
Display and edit 3xx device level features
à Reset
Reset the selected 3xx device
à Modem Product View
Graphical display of T3 2x4x or T1 2x6x products
showing circuit level with redundancy if installed
à Alarm Monitor
Alarms filtered for all modems on this circuit –
local, remote and redundant
à Telnet
Telnet to the DMM managing the domain
à Status
Circuit level status
à Configuration
Display and edit modem level features
à Reset
Circuit level reset for one or more modems
à 600x Product View
à Alarm Monitor
Alarms filtered for the 600x device selected
à Telnet
Telnet to the DMM managing the domain
à Status
à Configuration
à Reset
à 6100 Product View
à Alarm Monitor
à Telnet
Telnet to the DMM managing the domain
