8829 Media Converter Canoga Perkins
7
4. Troubleshooting ........................................... 27
5. Technical Specifications ............................. 29
5.1 10BASE-FL Optical ..................................... 29
5.2 1310nm Laser (Single Mode) ...................... 31
5.3 1310nm ELED (Single Mode) ...................... 33
5.4 Electrical / Functional ................................. 35
5.5 Physical / Environmental ............................ 36
Appendix A - Limited Warranty ........................ 37
List of Figures
2-1 Top and Front View of 8829 ......................... 10
2-2 UTP Connector for 8829 .............................. 12
2-3 Fiber Optic Cable Connections ................... 13
2-4 8801 Rack Chassis ....................................... 16
3-1 8829 LED Indicators .................................... 19
3-2 8829 Fiber Optic Loss Budget ..................... 22
