8829 Media Converter Canoga Perkins
21
POL UTP Receive Polarity Reversed
(Yellow)
When lit, POL indicates that the UTP
port is receiving polarity-reversed data
3.2 UTP XOVER Switch
The converter can be configured to connect to ei-
ther standard DTE devices, or to repeaters (which
usually cross their XMT and RCV pairs internally)
without the need for special crossover cables.
To connect the 8829 Media Converter to a stan-
dard DTE device with a standard straight-through
cable, set the XOVER switch to the X (internally
crossed) position.
To connect the 8829 Media Converter to any
10BASE-T port marked with an X (such as most
repeaters) with a standard straight-through cable,
set the XOVER switch to the N (normal) posi-
tion.
