8829 Media Converter Canoga Perkins
15
Set the XOVER switch to 'N' if connecting to a Re-
peater, or to 'X' if connecting the UTP to a com-
puter.
To cable the 8829 Media Converter for the fiber
interface, attach the receive fiber (connected to a
transmitter at the far end) to the Rx connector; at-
tach the transmit fiber (connected to a receiver at
the far end) to the Tx connector. These connectors
are located at the rear panel of the 8829 Media Con-
verter.
2.4.2 Rack Mount Installation
Up to twelve 8829 Media Converters can be in-
serted into a Canoga Perkins 8801 Model Rack
Chassis for cabinet installation (see Figure 2-4).
The chassis accommodates either the 8829-401-0
or 8829-601-0. Power is provided in the chassis.
Refer to Section 2.4.1 for data cabling instructions.
Refer to the Canoga Perkins 8801 Model Rack
Chassis User Manual for 8829 Media Converter
(powered rack) installation instructions.
