Canoga Perkins 8829 Media Converter
20
Rx Receive Data, Fiber to UTP (Green)
When blinking, Rx indicates that the
converter is receiving packets via the
fiber optic cable.
Tx Transmit Data, UTP to Fiber (Green)
When lit, Tx indicates that the con-
verter is transmitting packets onto the
fiber optic cable.
JAB Jabber Indicator (Red)
When lit, JAB indicates that the Fiber
port is receiving an excessively long
packet transmission and is blocking for-
warding to UTP.
LNK UTP 10BASE-T/Interface Integrity
Indicator (Green)
When lit, T/INF indicates that a Keep
Alive Signal or data packets are being
correctly received at the UTP input to
the transceiver. In order for the
10BASE-T link to be active, the F/INF
indicator must be ON.
