8829 Media Converter Canoga Perkins
25
3.3.3 Single Mode 1310nm ELED
The 8829 1310nm ELED UTP-to-Fiber Optic Media
Converter typically has a 13dB loss budget mini-
mum at 25
° C.
In addition, the same connector and cable attenu-
ation loss parameters called out for the 1310nm
Laser apply to the 1310nm ELED.
NOTE: The ELED version is susceptible to
temperature variations and the following rela-
tionship should be kept in mind when deter-
mining loss budget requirements.
••••• As the temperature increases from the
specified 25
°°°°° C by one degree increments,
the loss budget should be reduced by 0.18 dB.
••••• Conversely, as the temperature decreases
from 25
°°°°° C in one degree increments, the
loss budget may be increased by 0.18dB.
