Fault Annunciations
6.5 Issued 4/95 SW 06/07/08/11
❏ Installation with an RDS 81,
RDS 82 or RDS 82VP with soft-
ware 07 or later, “RANGE” will
annunciate when the 5 NM, 320
NM or 1000 NM range is selected.
❏ Installation with software 06
“WX FLT” (weather fault) will
annunciate when the 5 NM or
320 NM range is selected.
These annunciations alert the
pilot of a range mismatch
because the RDS 81, RDS 82
and RDS 82VP do not support
these radar ranges.
◗ STB OFF
Displayed when stab off has
been selected or when the stabi-
lization reference is not present
at the radar.
◗ WAIT
Displayed when in VP mode and
one of the TRACK buttons is
pressed, indicating the radar will
perform the desired slicing func-
tion as soon as the antenna
returns to the last selected profil-
ing azimuth angle.
◗ TCAS FAULT MESSAGES
The TCAS ONLY display on an
MFD will be replaced with up to
six yellow fault messages. Dur-
ing this tie the annunciated TCAS
status will be either “TCAS FAIL”
or “NO TCAS” as appropriate.
Except for the status annuncia-
tion and fault messages, the dis-
play will be completely black.
The fault messages are listed in
order of priority with the highest
first. TCAS FAIL messages have
priority over NO TCAS mes-
sages, however both can be dis-
played simultaneously (up to six
total).
Note: The following is a com-
plete list of all TCAS II faults
that the EFIS will display, how-
ever some of these are not
applicable to TCAS I and will
not be generated by a TCAS I
processor. Refer to the TCAS
Pilot's Guide for more informa-
tion.
Note: In some installations a
remote annunciator may be
installed to provide full time
TCAS operational status.
Fault Messages for
TCAS FAIL:
PROCESSOR
UPPER ANTENNA
LOWER ANTENNA
Fault Messages for
NO TCAS:
RADIO ALT 1/2
RADIO ALT 1
RADIO ALT 2
XPDR 1/2
XPDR 1
XPDR 2
ATTITUDE
HEADING
RA DISPLAY 1/2
RA DISPLAY 1
RA DISPLAY 2
XPDR UPPER ANT
XPDR LOWER ANT
TCAS TO XPDR
CP TO XPDR
ALT 1/2 TO XPDR
ALT 1 TO XPDR
ALT 2 TO XPDR
