System Configuration
1.1
Issued 4/95
SW 06/07/08/11
GENERAL
The 5 tube EFS 50 system Elec-
tronic Flight Instrumentation Sys-
tem) offered on the Lear 31A
consists of:
• 2 ea EHSI Display Unit
(ED 551A)
• 2 ea EADI Display Unit
(ED 551A)
• 1 ea MFD (ED 551A)
• 2 ea EFIS Control Panels
(CP 467)
• 1 ea MFD Control Panel
(CP 469 or CP 469A)
• 1 ea RADAR Control Panel
(CP 466A/B)
• 3 ea Symbol Generators
(SG 465)
• 1 ea Switching Unit
(SU 463)
CONTROL DISPLAY
Refer to figure 1.1 for the Control
Display configurations.
The CP 467 Control Panel con-
trols the presentation displayed
on the ED 551A Display Unit
when it is utilized as an EHSI or
EADI. The CP 469/A and CP
466A/B Control Panels control
the ED 551A Display Unit pre-
sentation when it is utilized as an
MFD (Multi Function Display).
Figure 1.1 depicts the EFS 50
Control Display Configurations.
SYSTEM CONFIGURATION
