SBY places the Mode S Transponder and TCAS in standby. SBY is
annunciated in the display window. Use standby during ground oper-
ations.
ON activates the selected transponder without altitude reporting.
TCAS is in standby. ON is annunciated in the display window.
ALT Activates Mode S transponder with altitude reporting, TCAS sys-
tem in standby.
VFR Selecting VFR for more than 3 seconds changes the ATC code
to the pre-programmed VFR code (typically 1200). VFR is annunciat-
ed in the display window for the 3 seconds before switching to the
programmed code. The control unit will return to the mode selected
prior to making the VFR selection. The VFR code can be pro-
grammed to any code by the following technique:
1. Place the function selector to VFR.
2. Select the VFR code as required.
3. Push the Ident (IDT) button, or wait 3 seconds, or rotate the
Function switch to the desired mode.
TA (TA Traffic Advisory) mode. TA activates the Mode S transpon-
der, altitude reporting and TCAS "TA ONLY" mode. Traffic will be
presented on the traffic (TA) display. "TA" mode is annunciated in
the control unit display window and "TA ONLY" will be annunciated
on the TCAS traffic display(s).
The inner concentric knob on the right selects the 4096 ATC code
and when pushed and held for more than four seconds switches the
TCAS traffic display to the FL (flight level) display function. To select
an ATC code, momentarily push this knob to start the left hand digit
in the ATC code flashing, twist the knob to change the number.
Momentarily push the knob again to move the flashing digit one
space to the right and twist the knob to change the digit. Repeat for
the third and fourth digit of the ATC code. The flashing digit will stop
flashing 3 seconds after the last change.
The traffic display switches to the FL (flight level) display function
when the inner knob is pressed in for more than four seconds. The
relative altitude tags are replaced with absolute altitude (FL) tags.
The traffic display will revert to relative altitude after 15 seconds.
