4
NOTE: Recommended service space is 3 ft-0 in.
at compressor motor end to allow for motor
removal.
DIMENSIONS (in.)
06E UNIT VOLTAGE A B C D E F G
V022
208/230 48 1 /
4
35 36 7 /
8
1 1 /
2
27 1 /
2
1 19 1 /
2
460,575 48 1 /
4
29 36 7 /
8
1 1 /
2
26 1 19 1 /
2
W027
208/230 50 1 / 4 35 36 7 / 8 1 1 / 2 27 1 / 2 1 19 1 / 2
460,575 50 1 /
4
29 36 7 /
8
1 1 /
2
26 1 19 1 /
2
W033
208/230 50 1 / 4 35 36 7 / 8 1 1 / 2 27 1 / 2 1 19 1 / 2
460,575 50 1 /
4
29 36 7 /
8
1 1 /
2
26 1 19 1 /
2
W044
208/230 50 1 /
4
35 36 7 /
8
1 1 /
2
27 1 /
2
1 19 1 /
2
460,575 50 1 /
4
35 36 7 /
8
1 1 /
2
27 1 /
2
1 19 1 /
2
Fig. 3 — 06E Hermetic Compressor Units
Fig. 4 — 06E Compressors
