Switching Waveforms
Figure 4. Read/Write/Deselect Sequence waveform for 2.0 Cycle Read Latency
[30, 31, 32]
tKH tKL tCYC tKHKH
NOP READ NOP WRITE READ WRITE
1 2 3 4 5 6 7 8
t t
t tSA HA
SC HC
tHD
tSC tHC
A0 A1 A2 A3
t
t
SD
HD
t SD
D11 D10 D12 D13 D30 D31 D32 D33 D
A
WPS
RPS
K
K
DON’T CARE UNDEFINED
CQ
CQ
tCQOH
CCQO
t
tCQOH
CCQO
t
tQVLD
QVLD
tQVLD
(Read Latency = 2.0 Cycles)
CLZ
t
t
CO
tDOH
tCQDOH
CQD
t
tCHZ
Q00 Q01 Q20 Q02 Q21 Q03 Q22 Q23
tCQH t
CQHCQH
Q
Notes
30. Q00 refers to output from address A0. Q01 refers to output from the next internal burst address following A0, that is, A0+1.
31. Outputs are disabled (High-Z) one clock cycle after a NOP.
32. In this example, if address A2 = A1, then data Q20 = D10 and Q21 = D11. Write data is forwarded immediately as read results. This note applies to the whole
diagram.
