AudioCodes Mediant 1000 Installation Guide — Page 9
Configuration > Advanced Applications > FXO Settings
Dialing Mode One Stage
Configuration > Protocol Configuration > Protocol Definition > DTMF & Dialing
This controls DTMF collection on both FXO (inbound dial) and FXS (outbound dial) ports. If you are not using FXS ports,
and are doing DTMF collection on the FXO ports, then you can decrease the values here to slightly decrease call times.
For example, if you are collecting 4 digits on the FXO ports, try these timings:
Max Digits in Phone Num 4
Inter Digit Timeout for Overlap Dialing 1
Hotline Dial Tone Duration 2
Test after making any changes to verify all DTMF digits are still being captured.
Burn Configuration Changes
IMPORTANT: Click the “Burn” button at the top of the page so that the configuration will be permanently saved to flash
memory. If you do not click “Burn,” any changes you made will be lost when the device reboots.
Media Gateway Configuration Examples
Only a PRI Module
This example Mediant has only a single PRI module installed.
Trunk Groups
Group
Index Module
From
Trunk
To
Trunk Channels Phone Number
Trunk
Group ID
1 Module 1 PRI 1 1 1-23 1000 1
Tel to IP Routing
Dest Phone Prefix Source Phone Prefix -> Dest IP Address
1 * *
The “Dest IP Address” above is the IP Address of the NET SatisFAXtion Fax Server.
IP to Trunk Group Routing
Dest Phone Prefix
Source Phone
Prefix Source IP Address -> Trunk Group ID
1 * * * 1
