AudioCodes Mediant 1000 Installation Guide — Page 11
Tel to IP Routing
Dest Phone Prefix Source Phone Prefix -> Dest IP Address
1 * 3605550100
2 * 3605550101
3 * 3605550102
4 * 3605550103
5 * 5035550197
7 * 5035550154
8 * 5035550129
9 * 5035550198
9 * *
Here we see each possible FXS phone number (defined in the trunk group above) routed to the Fax Machine Integration Server
(FMIS). All other faxes are routed to the NET SatisFAXtion Fax Server.
IP to Trunk Group Routing
Dest Phone Prefix
Source Phone
Prefix Source IP Address -> Trunk Group ID
1 * * 1
* * 2
We route all calls from the NET SatisFAXtion Fax Server out the PRI, and all calls from the Fax Machine Integration Server
(FMIS) to the FXS ports.
Mixed FXO and FXS Modules
This example Mediant has two FXO modules (8 FXO ports) and two FXS modules (8 FXS ports) installed.
Trunk Groups
Group
Index Module
From
Trunk
To
Trunk Channels Phone Number
Trunk
Group ID
1 Module 1 FXO 1-4 1000 1
2 Module 2 FXO 1-4 2000 1
3 Module 3 FXS 1-4 3605550100 2
4 Module 4 FXS 1 5035550197 2
5 Module 4 FXS 2 5035550154 2
6 Module 4 FXS 3 5035550129 2
7 Module 4 FXS 4 5035550198 2
In the above table, Module 2 FXS is assigned a phone number range of 3605550100 through 3605550103. The ports in Module
3 FXS are each assigned a unique phone number.
