Only FXO Modules
This example Mediant has three FXO modules installed for a total of twelve FXO ports.
Trunk Groups
Group
Index Module
From
Trunk
To
Trunk Channels Phone Number
Trunk
Group ID
1 Module 1 FXO 1-4 1000 1
2 Module 2 FXO 1-4 2000 1
3 Module 3 FXO 1-4 3000 1
Tel to IP Routing
Dest Phone Prefix
Source Phone
Prefix -> Dest IP Address
1 * *
The “Dest IP Address” above is the IP Address of the NET SatisFAXtion Fax Server.
IP to Trunk Group Routing
Dest Phone Prefix
Source Phone
Prefix Source IP Address -> Trunk Group ID
1 * * * 1
Mixed PRI and FXS Modules
This example Mediant has one PRI module and two FXS modules (8 FXS ports) installed.
Trunk Groups
Group
Index Module
From
Trunk
To
Trunk Channels Phone Number
Trunk
Group ID
1 Module 1 PRI 1 1 1-23 1000 1
2 Module 2 FXS 1-4 3605550100 2
3 Module 3 FXS 1 5035550197 2
4 Module 3 FXS 2 5035550154 2
5 Module 3 FXS 3 5035550129 2
6 Module 3 FXS 4 5035550198 2
In the above table, Module 2 FXS is assigned a phone number range of 3605550100 through 3605550103. The ports in Module
3 FXS are each assigned a unique phone number.
