Before You Begin
There are a few things you will need before you get started installing your new NET SatisFAXtion Mediant 1000 appliance.
Two Ethernet patch cables. •
A 19” rack or other place to mount the appliance. Rails may be needed depending on rack hardware. •
Two static IP addresses on the same subnet. •
Sufficient telephone and/or ISDN PRI cables to connect the telephony modules. •
If using T1 or PRI trunks, you will need the exact configuration specification from the trunk provider (telco). •
A PC connected to the same subnet the appliance will be on. The PC will need a web browser and a Remote Desktop (RDP) •
client.
In addition, the following are recommended.
An Uninterruptable Power Supply (UPS) with USB monitor interface. •
Connecting the Appliance to the Network
Media Gateway: On the front of the appliance you will see two RJ45 Ethernet connections on the “CPU” module labeled “I”
and “II”. Connect “I” to your network using an Ethernet patch cable.
OSN Module: On the back of the appliance you will see one RJ45 Ethernet connection on the “iPMX” module labeled with a
network symbol. Connect it to your network using an Ethernet patch cable.
Plug the power cable in, the appliance will power on after a short pause.
On the PC, configure its IP address:
IP Address 10.1.10.200
Subnet Mask 255.255.0.0
You will now be able to access and configure the appliance.
Accessing the Media Gateway via Browser
Media Gateway IP Address 10.1.10.10
Open a web browser, and navigate to http://10.1.10.10/
You will see a login prompt. Enter
User Admin
Password Admin
Accessing the NET SatisFAXtion Server via RDP
OSN Module IP Address 10.1.10.12
Run a Remote Desktop (RDP) client. On most versions of Windows, this can be found under Start > All Programs >
Accessories > Communications > Remote Desktop Connection.
In the “Computer” field, enter 10.1.10.12 and click “Connect.” When you see a login prompt, enter
User NetSat
Password on_demand
You will then see the NET SatisFAXtion server’s desktop.
Assign Static IP Addresses
The first step is to assign static IP addresses to the two components of the appliance so you can configure them on the regular
network.
