Vernier LabPro User Manual
Page 22
18
Vernier LabPro User’s Manual
7. The updated Time Graph Settings are displayed. Select
to return to the main screen.
8. EasyData is now set for triggering. When
is selected, data collection will not begin until the
set trigger value is met.
Manual Triggering
In manual triggering, data collection starts when the Start/Stop or Trigger button on the data-collection
device (LabPro, CBL 2, CBR, or CBR 2) is pressed. Follow these steps to set up for manual triggering.
1. From the EasyData main screen, select
, and then select Time Graph...
2. The current Time Graph settings are displayed. Select
.
3. The Select Trigger Type screen is displayed. Choose Manual and select
.
4. The updated Time Graph Settings are displayed. Select
to return to the main screen.
5. EasyData is now set for triggering. Select
and follow the on-screen instructions when you are
ready to start data collection.
