Plastic parts for use – OFNA Racing Ultra LX 1e User Manual
Page 5
30674
SERVO SAVER
40019
FRONT STIFFENER
41033
STONE GUARD
16016
WING
30270
WING STAY
PLASTIC PARTS FOR USE
SYMBOLS USED THROUGHOUT THE INSTRUCTION MANUAL
Ensure
Free
Movement
Ensure Free
Movement
Apply
Grease
Apply Lubricant
Oil
Tighten
Tighten
Do Not
Over Tighten
Rotate
Direction
Rotate
Direction
Contact
Adhesive
Contact Adhesive
c
w
S re
C me t
e
n
BAG
1:1
Parts Bag Used
Degrease With
Motor Spray
Do Not
Over Tighten
Clockwise
Rotation
Anti-clockwise
Rotation
True-To-Scale
Apply Oil
Apply Screw
Cement
30662
BATTERY CASE
