Page 15

Step 3

Step 2

94003
3x10mm
Hex Screw

.....x2

ASSEMBLY OF THE REAR TORQUE RAD

Step 1

3x10mm

94007
3x20mm
Hex Screw

.....x1

94013
3x25mm
Hex Screw

.....x1

36850

36850
7mm Ball

.....x1

36700

40108

36680

3x20mm

94041
3mm Nylon Nut

.....x1

3mm

3x25mm

36680
7mm Ball and Socket

.....x1

*Approx. 42mm

36710

ASSEMBLY OF THE MAGIC TAPE INTO BATTERY CASE

Step 1

Step 2

30662

30663
