12

ASSEMBLY OF THE SERVO SAVER ONTO GEAR CASE

Step 1

Step 2

5

3x15mm

3x10mm

3x15mm

40039

rew

Sc

ement

C

Screw

e e

C m nt

40039

94003
3x10mm
Hex Screw

.....x2

94021
3x15mm
Flat Head Hex Screw

.....x4

40039
3mm
Tapered Washer(Alum.) .....x4

13

ASSEMBLY OF THE REAR GEAR CASE

Step 1

Step 2

30010

30130

30630

30630

30080

5x4mm

Apply
Grease

94036
5x4mm
Set Screw

.....x1

30630
6x13x5mm
Ball Bearing

.....x2

Apply
Grease

Scr

ew

Cem

n

e t

14

ASSEMBLY OF THE REAR GEAR CASE

Step 1

Step 2

30010

4x25mm

3x18mm

30649

30351

30351

4x16mm

94022
3x18mm
Flat Head Hex Screw

94027
4x16mm
Flat Head Hex Screw

.....x2

.....x2

94029
4x25mm
Flat Head Hex Screw

.....x2

3x15mm

40039

Set triangle marks in
the direction shown
in Fig.(1)

1
Degree

1.5
Degree

Fig.1

Use rear tor-in adjuster.
