Prs-20, prs-21 team race stand – Park Tool PRS-21 User Manual
Page 4
Park Tool Co.
5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com
© 2013 Park Tool Co. / PARK TOOL® and the color BLUE are registered trademarks of Park Tool Co.
Note: Washers should be used as required to account for variations in casting taper.
Part No.
Description
Qty.
1729A
Front Quick Release Assembly
1
1722A
Rear Quick Release Assembly
1
1728
Slider Tube Weldment
1
1721
Slider Rear Axle Extension
1
1706-2
Knob and Shaft
2
1715-2
Horizontal Beam End Cap
2
1716R
Horizontal Beam Tube (PRS-20 only)
1
1734R
Aluminum Horizontal Beam Tube (PRS-21 only)
1
1257-2
Saddle Button Head Socket Cap Screw 1/4 - 20 x 3/8”
2
1711R
Bottom Bracket Saddle
1
1283X
Pivot Button Head Socket Cap Screw M10 x 50
1
1723
Hitch Pin
1
1724-2
Bracket Washer
2
1285X
Pivot Screw Nylok Nut
1
1709L
Left Upright Bracket
1
1709R
Right Upright Bracket
1
1709S
Buckle & Strap Assembly
1
290
Nylok Nut
2
1709-2
Upright Bracket Bolt
2
1708
Upright Tube (PRS-20 only)
1
1733
Aluminum Upright Tube (PRS-21 only)
1
1707.2
Clamping Collar Quick Release Assembly
1
1701
Upright Sleeve
1
1705
Yoke Weldment (PRS-21 only)
1
1705-20
Yoke Weldment (PRS-20 only)
1
479-6
Leg Bolt 1/4 - 20 x 2”
3
1700-3
Leg Tube (PRS-20 only)
3
1732-3
Aluminum Leg Tube (PRS-21 only)
3
1780-2
Leg Cap
3
480-6
Leg Nylok Nut 1/4 - 20”
3
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
22
23
24
24
25
26
PRS-20, PRS-21
Team Race Stand
