Park Tool Co.

5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com

CTP-4K Replacement

Chain Tool Pin Kit for

CT-4 / CT-4.2 / CT-4.3 / CT-11

Chain Tool Pin Replacement:

a. Unthread plunger (#1) from body (#2).
b. Unthread nut (#4) from plunger.
c. Pull pin (#5) from plunger, taking care the bearing (#3) inside

the plunger does not fall out. Install new pin. Note: One

replacement bearing is included with the CTP-4K in the event

the original bearing in the chain tool is lost or damaged.

d. Thread nut onto plunger.
e. Thread plunger into body.

Austausch des Kettennietstiftes:

a. Die Spindel (#1) vollständig aus dem Werkzeugkörper (#2) drehen.
b. Die Stift-Sicherungsmutter von der Spindel drehen.
c. Den Nietstift aus der Spindel herausziehen ohne dass die

Kugellagerung herausfällt und neuen Nietstift einsetzen.

d. Die Stift-Sicherungsmutter auf die Spindel schrauben.
e. Die Spindel in den Werkzeugkörper eindrehen.

Remplacement du poinçon du dérive chaine:

a. Retirer le plongeur (#1) du corps (#2).
b. Retirer l’écrou (#4) du plongeur.
c. Retirer le poinçon du plongeur, tout en faisant attention

à ne pas faire tomber la bille (#3). Installer le nouveau

poinçon. Note: Une bille de remplacement est fournie avec

le CTP-4K, dans l’éventualité où la bille originale soit perdue

ou abimée.

d. Revisser l’écrou sur le plongeur.
e. Revisser le plongeur sur le corps.
