Park Tool Portable Wheel Dishing Tool - Manual (Page 2)

Park Tool Co. 5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com
Part No. Description Qty.
1113 Upper Leg 1
1114 Lower Leg 1
1112 Gauge Block 1
1126 Washer 1
1127 Spring 1
1124 Gauge Knob 1
1125 Gauge 1
1279X-4 Button Head Cap Screw 1
542 Carriage Bolt 2
1117-2 Wing Nut 2
WAG-5 part numbers
1
2
3
4
5
6
7
8
9
10
Figure-1 Figure-2 Figure-3 Figure-4
1
2
8
10
9
3
5
4
7
6
