DESCRIPTION
INDEX Nº
PART Nº
Illustrated Parts List
GEMTIF
* SUGGESTED PARTS TO STOCK
1
2
3
4
5
6
7
8
8A
9
10
11
12
13
13A
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42A
43
44
45
46
47
GEM3IF
WC-37121*
WC- 442
WC-2977-101K*
WC- 844-101*
WC-39744
WC-37388*
WC-39755*
WC-39756*
WC-29050*
WC-8559*
WC-3417*
WC-39745
WC-61960
WC-61960-BLK
WC-61963
WC-38504
WC-61962
WC-37008*
WC-43067*
WC-5502-01*
WC- 934-04*
WC-4382*
WC-1438-101*
WC-62033
WC-29044
WC-2402P*
WC- 847 *
WC-37122 *
WC-1501*
WC- 102*
WC- 522 *
WC-43055*
WC-61955
WC-3528 *
WC-1809*
WC-5310*
WC-5231*
WC-3765L*
WC- 571K-R
WC- 571K-L
WC-43133
WC-5350*
WC-61954
WC-61954-BLK
WC-37266*
WC-37317*
WC-37365*
WC-37132*
GEM-6
SATELLITE, INTELLIFRESH
DUMP VALVE LEFT
SOLENOID, LOCK BREW CONE RIGHT 120V
KIT, SPRAYHEAD FITTING, GASKET, & JAM NUT
VALVE, BY-PASS, NON-ADJUSTABLE W/RSTRCTR
LABEL, UCM & OUTER 3-BATCH GEM-IF
KIT, LABEL & UCM GEMTIF 3-BATCH CURTIS
LABEL, UCM OVERLAY 1-BATCH
LABEL, UCM OVERLAY 2-BATCH
SPRAYHEAD, AFS-AMBER
RELAY, SOLIDSTATE 40A W/HEAT SINK
BREW CONE, ASSY W/SPLASH POCKET BROWN COFFEE
LABEL, BOTTOM PANEL
COVER, FRONT WELD ASSEMBLY SS
COVER, FRONT WELD ASSEMBLY BLACK POWDER COAT
HOLDER, IF CONNECTORS FEMALE GEMTIF
LABEL, WARNING SHOCK HAZARD
DECK, WARMER WELD ASSY
KIT, TANK LID ROUND
O’RING, 4.5” ID SILICONE
KIT, PROBE, ASSY WATER LEVEL W/FITTING, O-RING, NUT
ELEMENT HEATING 2.5KW 220V
GUARD, SHOCK HEATING ELEMENT
SENSOR, HEATING TANK
TANK, COMPLETE GEMTS NON-METAL FITTINGS
SLEEVE, OVERFLOW ASSY GEN USE
ELBOW, 3/8”FL x 3/8” NPT PLATED
VALVE, INLET 2 GPM 120V 10W GEN USE YEL BODY
DUMP VALVE RIGHT
FUSE HOLDER ASSY W/5A FUSE
SWITCH, RESISTIVE TOGGLE NON-LIT SPST 125/250VAC
THERMOSTAT, RESET
GUARD, SHOCK RESET T-STAT
COVER, TOP SS
LEG, 4” ADJUST 3/8-16 THREAD STYLIZED
FAUCET, PS/HPS SERIES HOT WTR
TUBE, 5/16 ID x 1/8W SILICONE
COMPOUND, SILICONE
KIT, VALVE REPAIR USE ON WC-847
KIT, IF CONNNECTOR-RIGHT
KIT, IF CONNECTOR- LEFT
O-RING, 1.424ID X 1.630 OD X .103 WALL GEMIF’s
TUBE, SILICONE Ø1/2” ID x Ø3/4” OD x 1/8” WALL
PLATE, BREWCONE STOP STAINLESS STEEL
PLATE, BREWCONE STOP BLACK POWDER COAT
KIT, TANK OVERFLOW FITTING WITH BUSHING
KIT, STRAIGHT FITTING WITH BUSHING
KIT, TANK INLET FITTING WITH BUSHING
KIT, VALVE REPAIR USE ON WC-844-101
FILTER, 500/PKG
