Wilbur Curtis GEM3IF - Manual (Page 15)

15
* SUGGESTED PARTS TO STOCK
Illustrated Parts List
GEM3IF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 WC-5622*
WC-2001
WC-2005*
WC-2025*
WC-2010C
WC-2006*
WC-2102
WC-39747
WC-2007
WC-6417
WC-1901A
WC-1800*
WC-37543*
WC-37544*
WC-39746
WC-37545*
WC-3705*
WC-38151
WC-13426
WC-39747 LID, BLACK PLASTIC GEM-3
CAP, SHIELD W/VENT
WASHER, SHIELD CAP 1/8”
GLASS, GAUGE 8”
SHIELD, GAUGE GLASS ¾” D. x 8”
WASHER, .188ID x .188 THK BOTTOM
GAUGE GLASS ASSEMBLY 8”
LABEL, SIDE GEM3IF CURTIS LOGO
BRACKET, GAUGE GLASS GEM-3
GUARD, FAUCET GEM-3
SHANK, FAUCET W/SHIELD BASE
FAUCET, S’ SERIES NON-LOCKING
KIT, INTELLIFRESH HEATER GEM3IF
KIT, RED LED LIGHT GEM3IF
LABEL, FRONT GEM3IF CURTIS LOGO
KIT, HYBRID TEMPERATURE CONTROL
KIT, FAUCET S’ SERIES
LABEL, LOCK/UNLOCK GEM3
IF CONNECTOR, FEMALE W/WIRES
LABEL, SIDE GEM-3IF CURTIS LOGO
Rough-In Drawing
GEM3IF
DESCRIPTION INDEX Nº PART Nº
