Parts List and Electrical Schematics
GEM5IF & GEM5IFT
The GEM5IFS (single warmer stand) and the GEM5IFT (twin warmer stand) use some common parts. Items
that are exclusive to the GEM5IFT are indicated in bold type in the parts list.
LABEL, SLIDE CONTAINER
LABEL, WARNING SHOCK HAZ
RETAINER, GEM5IFS
RETAINER, GEM5IFT
COVER, TOP GEM-5IS
COVER, TOP GEM5IFT
LABEL, FRONT GEM5IFS
LABEL, FRONT GEM5IFT
SWITCH, ROCKER (RED) SPST
COVER, BOTTOM ASSY GEM5IFS COVER, BOTTOM ASSY GEM5IFT
LEG, 3/8”-16 STUD BUMPER
LEG, 4” ADJUSTABLE 3/8-16 THRD
LEG, 2½’ ADJUSTABLE SATIN
BOX, IF MODULE GEM-5IF
HOLDER, CONNECTOR FEMALE
HARNESS ASSY IF CON RT
HARNESS ASSY, GEM5IFS
HARNESS ASSY GEM5IFT WC-38535
WC-38504
WC-61317
WC-61383
WC-61315K
WC-61382K
WC-39750
WC-39810
WC- 114R
WC-61326 1
2
3
3A
4
4A
5
5A
6
7 WC-61387
WC-3503
WC-3500 *
WC-3512 *
WC-61318
WC-61307
WC-13429
WC-1386
WC-13435 7A
8
8A
8B
9
10
11
12
12A
INDEX № PART № DESCRIPTION INDEX № PART № DESCRIPTION
* OPTIONAL
1
2
3
3A
4
4A
5
5A
6
7
7A
9
10
11
12
12A
A
