UNPACKING

All products manufactured by the Wilbur Curtis Company are

thoroughly inspected at the factory and are warranted to be

free of all defects and faulty workmanship. These brewers are

packaged for maximum protection during shipping.

Make sure the shipping carton is not damaged or punctured.

Unpack the carton, carefully inspecting the contents for any

damage that may have occurred in transit.

SHIPPING CARTON CONTENTS & UNPACKING

STANDARD ITEMS

ROUGH-IN

DRAWINGS

16½"

2"

17 "

11¾"

13¼"

9"

6½"

17 "

6 "

2¼"

1 "

TOP VIEW

7½"

8

7

8

7

8

7

8

1

ELECTRICAL

BREW SETUP

HALF BREW, 1.1 LITER

FULL BREW, 2.2 LITERS

CORD & PLUG

6 Ft./NEMA 5-15P (120V Units Only)

WATER HOOK-UP ELBOW, FLARE 1/4 x 3/8 FITTING, WATER CONNECTION

CONTENTS

AND

UNPACKING

3

Volts

TLP Model Nº

Watts

Amps

Hertz

TLP10 Model Only

Coffee Brewer, ThermoLogic Low Profile
Brew Cone
Elbow, ¼ x

?

Flare

Paper Filters
Service Manual, TLP

1
1
1

25

1

TLP
WC-3621
WC-2401
CR-10
F-3206

Qty Item

Part Nº

3 8

TLP10
TLP20
TLP15
TLP30
TLP61

120V
120V
220V
220V

120/220V

1700W
1500W
3600W
3600W

1700/3600W

14A

12.5A
16.5A
16.5A

14/16.5A

2W+G
2W+G
3W+G
2W+G

2W/3W+G

Wires

50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz

12

12
