Wilbur Curtis TLP61 - Manual (Page 18)

PARTS LIST
GENERAL PARTS
18
ITEM ITEM ITEM ITEM ITEM N NN NNººººº PART PART PART PART PART N NN NNººººº DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION
1 WC-3621 CONE, UNIVERSAL BREW 7 1/8 BLK PLASTIC
1A WC-3316 BREWCONE W/BASKET, S/S STD 7 1/8
2 WC-5450 COVER, TOP
3 WC-39321 MEMBRANE, CONTROL PANEL CURTIS
4 WC-1438-101 SENSOR, TEMPERATURE TANK
5 WC-29030 SPRAYHEAD ASSY, ADVANCED FLOW ORANGE
6 WC-2962 FITTING, SPRAYHEAD ASSY
7 WC-29037 RESTRICTOR, ELBOW PP RED
8 WC-3765 KIT, INLET VALVE REPAIR (FOR WC-826, WC-856)
9 WC-58085 COVER, SIDE
10 WC-8556 HEATSINK ASSY
11 WC- 761 CONTROL BOARD, 120V TLP (Models 10, 20, 15, 61)
11A WC- 771 CONTROL BOARD, 220V TLP (Model 30)
12 WC-1040 PUMP, WATER CENTRIFUGAL 120V 60 Hz (Models 10, 20, 15, 61)
12A WC-1042 PUMP, WATER CENTRIFUGAL 220V 60 Hz (Model 30)
13 WC- 889 VALVE, LIQUID DISPENSING LEFT 120V 12W (Models 10, 20, 15, 61)
13A WC- 860 VALVE, LIQUID DISPENSING LEFT 220VAC 12W (MODEL 30)
14 WC-5231 COMPOUND, SILICONE 5 OZ TUBE
15 WC-3503 LEG, SCREW BUMPER 3/8” - 16 STUD
16 WC- 102 SWITCH, TOGGLE SPST 25A 250VAC RESISTIVE (Models 10, 20)
16A WC- 103 SWITCH, TOGGLE DPST 25A 125/250 VAC RESISTIVE (Models 15, 30, 61)
17 WC- 826 VALVE INLET 1.15 GPM 120V 10W (Models 10, 20, 15, 61)
17A WC- 856 VALVE, INLET 1.15 GPM 240V 10W (Model 30)
18 WC-54107 TANK, COMPLETE W/1600W HEATER (Model 10)
18A WC-54123 TANK, COMPLETE W/1450W HEATER (Model 20)
18B WC-54124 TANK, COMPLETE W/3500W HEATER (Models 15 & 30)
18C WC-54127 TANK, COMPLETE W/1600W AND 3500W HEATER (Model 61)
19 WC-43062 GASKET, TANK LID
20 WC-5851 COVER, TANK W/NOTCHES
21 WC-5502 PROBE ASSY, WATER LEVEL
22 WC- 523 THERMOSTAT, MANUAL RESET 120/220 VAC 25A 220 DEG F MAX
23 WC- 904 ELEMENT, HEATING 1,600W 120V (Model 10 & 61)
23A WC- 917 ELEMENT, HEATING 1,450W 120V (Model 20)
23B WC- 922 ELEMENT, HEATING 3,500W 220V (Models 15, 30 & 61)
24 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
25 WC-8591 CAPACITOR, X2
