Key Definitions
Handheld Transmitter: Transmits the radio signal to the Receiver
Collar. It is water resistant.
Transmitter Indicator Lights: Indicate that a button is pressed
and also serve as a low-battery indicator.
Red LED: Factory set for One Dog training. Indicates low battery
and when the stimulation button is pressed. Also shows when the
Transmitter is being charged.
Green LED: For Two Dog training. Indicates when the stimulation
button is pressed for Dog 2.
Level Select Switch: Provides multiple levels of Vibration Stimulation.
Level Select Indicator: Shows level of Vibration Stimulation.
Top Button (light blue): Delivers a quick Vibration Stimulation
followed by controlled Vibration Stimulation when button is pressed.
Green LED
(for 2 Dog)
Level Select Switch Level Select
Indicator
Antenna
Dog Select
Button
Top Button
(light blue)
Lanyard
Attachment
Charging Jack
& Dust Cover
Battery
Door Cover
Red LED
