340A Integrated amplifer
azur integrated amplifier 9
Tape connection
The following diagram shows how to connect the amplifier to a tape
recorder or other source with a record and monitor connection.
Using Speaker B connections
The Speaker B connections on the back of the amplifier allow a second
set of speakers to be used, which could be for another room.
