1. Turn the cutter on, you will see SELECT | ROLL on the display
2. Press the MENU button on the display
3. Rotate the BLUE jog wheel clockwise until you see WIDTH | XXXmm on the display
4. Press the MENU button until the cursor is flashing on
5. Rotate the BLUE jog wheel clockwise until you see the correct size required on the display
6. Press the ENTER key to save your size
7. Rotate the BLUE jog wheel clockwise until you see LENGTH | on the display
8. Repeat the process above (section 5) to set the appropriate length size
9. When you have entered the correct sizes in, rotate the BLUE jog wheel anticlockwise until
the display reads SELECT | ROLL
Roland CX-24 Media Sizes
Before inserting your A3 or A4 sized media into the cutter, you will need to check whether it
is set up correctly. To change this, follow the steps below (XXXmm represents the sizes in
bold below).
The Ultragraphics media sizes are as follows:
A4: Width 170mm x Length 247mm
A3: Width 257mm x Length 360mm
7
