APPENDIX A - Installation Instructions for the Epson R1800 Easy Flow IV
ITINERY
• (1) Bottles and cartridge assembly (pre-filled)
• (2a) Main tube support 1 (may vary in colour)
• (2b) Main tube support 2 (may vary in colour)
• (3) Small clamp
• (4) 10ml Syringe
• (5) Small needle (only required for re-priming, see page 8)
• (6) Large extension
• (7) 8 x air filters
• (8) Subli-Print CD (including .ICC colour profile & Instructions)
• (9) Small screwdriver (for lid removal)
1
2a
3
4
5
6
7
8
9
2b
