3D SMARTone INSTALLATION AND OPERATION
8
6. Decorating a part
•
When you are ready to decorate a part, open
the drawer.
•
Here is a look at the drawer in detail.
•
The platen and jig will become hot during the
process.
• This is the frame. This is used to clamp the
film into place.
• Raise it to load film.
•
When the frame is down, it rests against a
silicon foam seal.
•
Take care not to cause damage to the seal –
replacements can be fitted easily if necessary.
•
Clip the blank phone case onto the jig.
•
The top of the part should always go to the
left hand side (camera holes are normally
located at the top).
•
Extra care should be taken to ensure that the
case is clipped on in this way.
