3D SMARTone INSTALLATION AND OPERATION
16
3) All the segments of test lines should be present
As shown on left
If segments are missing the print nozzles need cleaning.
Press the appropriate nozzle clean button:
ie if magenta, yellow or cyan are affected press the colour
nozzle button, if black is affected press the black nozzle
button
NB Nozzle checks and cleaning can also be run from driver
software
Once the printer is set up load the driver software following the
instructions in the Epson documents.
USE USB CONNECTION
Accept the default settings.
Note: decline any requests for registration or updates from
Epson.
Windows XP
Windows 7
Once the driver is installed it must be configured.
Right click on printer and select ‘Printing Preferences’
