12
2650KGWA PARTS FOR MAINTENANCE
Field Replaceable Parts
Key No.* Part No. Description Qty.
1 B1109401-0 DISPLAY ASSEMBLY 1
11 B2033701-0 MAIN BOARD TO JUNCTION BOX LOAD CELL CABLE 1
18 B3823601-0 RIGHT RAMP BRACKET 2
22 B2138901-0 CONNECTOR BOARD 1
24 B1304202-0 LOAD CELL 4
29 B2266701-0 FOOT ASSEMBLY 4
33 B3823701-0 LEFT RAMP BRACKET 2
39 ADPT30 POWER ADAPTER 120V-240V 1
PROKIT INCLUDES ADAPTER, DISPLAY ASSY, 4 LOAD CELLS,
CONNECTOR BOARD, 4 FOOT ASSEMBLY 1
Below listed items are for reference only (refer to detailed view on page 11)
2 DISPLAY STAND 1
3 PHILLIPS PAN HEAD SCREW, M4 4
4 DISPLAY STAND FOOT 1
5 NON SKID PADS 4
6 SELF LOCK NUT, M3 2
7 WASHER, M3 2
8 SCREW, M3x10 2
9 INPUT / OUTPUT POSTS LABEL 1
10 BUMPER 4
12 RAMP #1 1
13 MAT 1
14 HEALTH O METER LABEL 1
15 SCREW, M8x19 4
16 HANDLE 1
17 PLATFORM ASSEMBLY 1
19 WASHER, M5 16
20 SCREW, M5x10 16
21 RAMP MAT 4
23 RAMP 1
25 SOCKET HEAD CAP SCREW 5/16-18x¾ 8
26 SCREW, M10x10 4
27 LOAD CELL SAFETY SCREW 4
28 SCREW, M4x6 2
30 SHEET METAL SCREW, #8x½ 26
31 BOTTOM COVER 1
32 SCOTCH MATE HOOK 2
34 SHOULDER BOLT 2
35 WHEEL 2
36 WHEEL CLIP ASSEMBLY 2
37 DOUBLE STICK TAPE 2
38 SCOTCH MATE LOOP 2
* See page 11 for a detailed view of parts by number.
