4
Control Codes and Escape Sequences
International Character Sets
Fax
Function Code Decimal Hex
Horizontal tab HT 9 09
Line feed LF 10 0A
Form feed FF 12 0C
Carriage return CR 13 0D
Cancel CAN 24 18
Double width on SO 14 0E
Double width off Si 15 0F
Set print mode ESC NULL ! n 27 0 33 n 1B 00 21 n
Set barcode start position ESC NULL $ n1 n2 27 0 36 n1 n2 1B 00 24 n1 n2
Set bit image (8 pin single density) ESC NULL * 0 n1 n2 [d] 27 0 42 0 n1 n2 [d] 1B 00 2A 00 n1 n2 [d]
Set bit image (8 pin double density) ESC NULL * 1 n1 n2 [d] 27 0 42 1 n1 n2 [d] 1B 00 2A 01 n1 n2 [d]
Set bit image (24 pin single density) ESC NULL * 32 n1 n2 [d] 27 0 42 32 n1 n2 [d] 1B 00 2A 20 n1 n2 [d]
Set bit image (24 pin double density) ESC NULL * 33 n1 n2 [d] 27 0 42 33 n1 n2 [d] 1B 00 2A 21 n1 n2 [d]
Underline on ESC NULL – 1 27 0 45 1 1B 00 2D 01
Underline off ESC NULL – 0 27 0 45 0 1B 00 2D 00
Reset ESC NULL @ 27 0 64 1B 00 40
Set page length ESC NULL C n 27 0 67 n 1B 00 43 n
Set horizontal tabs ESC NULL D n 27 0 68 n 1B 00 44 n
Set bit image ESC NULL K n1 n2 [d] 27 0 75 n1 n2 [d] 1B 00 4B n1 n2 [d]
Country select ESC NULL R n 27 0 82 n 1B 00 52 n
Double width on ESC NULL W 1 27 0 87 1 1B 00 57 01
Double width off ESC NULL W 0 27 0 87 0 1B 00 57 00
Compressed bit image graphics ESC NULL Z n1 [d1] … n24 [d24] 27 0 90 n1 [d1] … n24 [d24] 1B 00 5A n1 [d1] … n24 [d24]
Print & feed paper ESC NULL d n 27 0 100 n 1B 00 64 n
Label advance ESC NULL f 27 0 102 1B 00 66
Reversed on ESC NULL i 1 27 0 105 1 1B 00 69 01
Reversed off ESC NULL i 0 27 0 105 0 1B 00 69 00
Double height on ESC NULL w 1 27 0 119 1 1B 00 77 01
Double height off ESC NULL w 0 27 0 119 0 1B 00 77 00
Inverse on ESC NULL { 1 27 0 123 1 1B 00 7B 01
Inverse off ESC NULL { 0 27 0 123 0 1B 00 7B 00
Graphics ESC n [d] 27 n [d] 1B n [d]
Roman 8 character set ESC <248> 27 248 1B F8
ECMA 94 character set ESC <249> 27 249 1B F9
Underline off ESC <250> 27 250 1B FA
Underline on ESC <251> 27 251 1B FB
Normal width on ESC <252> 27 252 1B FC
Double width on ESC <253> 27 253 1B FD
Self test ESC <254> 27 254 1B FE
Reset ESC <255> 27 255 1B FF
Set barcode height (1 < n < 255) GS h n 29 104 n 1D 68 n
Print UPC-A barcode GS k 0 [d] NULL 29 107 0 [d] 0 1D 6B 00 [d] 00
Print UCP-E barcode GS k 1 [d] NULL 29 107 1 [d] 0 1D 6B 01 [d] 00
Print EAN13 barcode GS k 2 [d] NULL 29 107 2 [d] 0 1D 6B 02 [d] 00
Print EAN8 barcode GS k 3 [d] NULL 29 107 3 [d] 0 1D 6B 02 [d] 00
Print Code 39 barcode GS k 4 [d] NULL 29 107 4 [d] 0 1D 6B 04 [d] 00
Print 2 of 5 barcode GS k 5 [d] NULL 29 107 5 [d] 0 1D 6B 05 [d] 00
Print Codabar barcode GS k 6 [d] NULL 29 107 6 [d] 0 1D 6B 06 [d] 00
Print CODE128 barcode GS k 7 n [d] 29 107 7 n [d] 1D 6B 07 n [d]
Set barcode magnification (2 < n < 4) GS w n 29 119 n 1D 77 n
Country Code Decimal Hex
USA ESC NULL R 0 27 0 82 0 1B 00 52 00
France ESC NULL R 1 27 0 82 1 1B 00 52 01
Germany ESC NULL R 2 27 0 82 2 1B 00 52 02
UK ESC NULL R 3 27 0 82 3 1B 00 52 03
Denmark I ESC NULL R 4 27 0 82 4 1B 00 52 04
Sweden ESC NULL R 5 27 0 82 5 1B 00 52 05
Italy ESC NULL R 6 27 0 82 6 1B 00 52 06
Spain ESC NULL R 7 27 0 82 7 1B 00 52 07
Japan ESC NULL R 8 27 0 82 8 1B 00 52 08
Norway ESC NULL R 9 27 0 82 9 1B 00 52 09
Denmark II ESC NULL R 10 27 0 82 10 1B 00 52 0A
Martel Instruments Limited
Stanelaw Way, Tanfield Lea Industrial Estate, Stanley, Durham DH9 9XG, UK
Tel: +44 (0)1207 290266 Fax: +44 (0)1207 290239
Email: [email protected]
USA Sales Office: 14892 Trojan Circle, Huntington Beach, CA 92647
Tel: (714) 892-0086 Fax: (714) 892-0096
Email: [email protected]
Website: www.martelinstruments.com
MCP8850B/UG/B
© MARTEL
INSTRUMENTS
All instruments designed and
manufactured in Great Britain.
The manufacturer reserves
the right to alter specifications
without prior notice
